5 Drive interface
5.2 Device commands
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.2.24 Calculate inv. characteristic
If a motor of a third-party manufacturer with unknown motor parameters is driven by the
controller, the C00002 = "71: Determine inverter characteristic" device command can be used to
determine the so-called "Inverter error characteristic" for optimising the inverter switching
performance.

Tip!
Detailed information about the determination of the inverter error characteristic can be
found in the chapter "Motor interface" in the subchapter " Optimising the switching
performance of the inverter ". ( 183)
If the inverter error characteristic cannot be determined by means of this device command
or if the results of the determination are incorrect, the device command " Load Lenze INV
characteristic " can be used to load a characteristic typical for the device. ( 118)
Possible status displays for this device command
Related device commands
 Load Lenze INV characteristic ( 118)
Status ( C00003 ) Meaning
4687106 Device command in process
4653056 Device command executed successfully
4653057 General error
4692754 The calculation of the inverter characteristic cannot be started since the current controller
test mode is active.
4692755 The calculation of the inverter characteristic cannot be started since the V/f test mode is
active.
4692756 The calculation of the inverter characteristic cannot be started since the pole position
identification is active.
4692757 Calculation of the inverter characteristic has been aborted.
4692758 Calculation of the inverter characteristic has been interrupted by error.
4692789 Determined inverter error characteristic exceeds internal limits.
• This situation can for instance occur if the motor power is very much lower than the
device power.
