14 Diagnostics & fault analysis
14.7 Error messages of the operating system
686
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Encoder: Open circuit [0x007b001b]
Brake transistor: Ixt overload [0x007b001c]
Brake resistor: I²xt overload [0x007b001d]
Motor: Actual current value > C00620 [0x007b001e]
Module ID (decimal) Error ID (decimal)
123: Motor control 27
Response (Lenze setting printed in bold) Setting: C00580 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• Encoder cable interrupted.
• Encoder defective.
• Faulty parameter setting of the encoder.
• Interruption of the light path of laser measuring
systems.
• Insufficient reflection of the light of laser measuring
systems.
Note:
The encoder open-circuit monitoring for incremental
encoders ( C00422 = "0: Incremental encoder (TTL
signal)") requires a signal amplitude > 3.5 V!
If the signal amplitude is lower than 3.0 V, the error
response parameterised in C00580 is triggered.
• Check encoder cable.
• Check encoder.
• Check parameter setting ( C00422 ).
• Switch off the monitoring function ( C00580 ="3") if no
encoder is used.
• Correct the light path (for laser measuring systems).
• Improve the reflection (for laser measuring systems).
Module ID (decimal) Error ID (decimal)
123: Motor control 28
Response (Lenze setting printed in bold) Setting: C00573 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Too frequent and too long braking processes. Check drive dimensioning.
Module ID (decimal) Error ID (decimal)
123: Motor control 29
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Too frequent and too long braking processes. • Check drive dimensioning.
• Check parameter setting ( C00129 , C00130 , C00131 ).
Module ID (decimal) Error ID (decimal)
123: Motor control 30
Response (Lenze setting printed in bold) Setting: C00619 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The instantaneous value of the motor current has
exceeded the value set in C00620 .
• Set a higher value in C00620 .
• Reduce maximum current ( C00022 ).
• Change response ( C00619 ).
