15 Parameter reference
15.2 Parameter list | C02603
890
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02603
C02604
C02605
C02607
C02608
Parameter | Name:
C02603 | Threshold 1 for opening brake
Data type: INTEGER_32
Index: 21972
d
= 55D4
h
 Basic function " Brake control "
Setting range (min. value | unit | max. value) Lenze setting
-50000 rpm 50000 0 rpm
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02604 | Threshold 2 for opening brake
Data type: INTEGER_32
Index: 21971
d
= 55D3
h
 Basic function " Brake control "
Setting range (min. value | unit | max. value) Lenze setting
-50000 rpm 50000 0 rpm
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02605 | Brake test - time
Data type: UNSIGNED_16
Index: 21970
d
= 55D2
h
From software version V4.0
Setting range (min. value | unit | max. value)
0.001 s 65.535
Subcodes Lenze setting Info
C02605/1 1.024 s Brake test - ramp-up time
C02605/2 4.000 s Brake test - constant ph. time
C02605/3 1.024 s Brake test - ramp-down time
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1000
Parameter | Name:
C02607 | BRK_dnState
Data type: INTEGER_32
Index: 21968
d
= 55D0
h
Bit coded status of the basic function " Brake control ".
Display range (min. value | unit | max. value)
-2147483648 2147483647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02608 | BRK_dnTorqueAdd_n
Data type: INTEGER_32
Index: 21967
d
= 55CF
h
Display of the additive torque value of the basic function " brake control ".
Display range (min. value | unit | max. value)
-200.00 % 200.00
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
