14 Diagnostics & fault analysis
14.7 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Memory module is defect or missing [0x0068000c]
Safety module is defect or missing [0x0068000d]
Control card incompatible [0x0068000e]
Power section incompatible [0x0068000f]
MXI1: Wrong module [0x00680010]
Module ID (decimal) Error ID (decimal)
104: Module identification 12
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the memory
module.
• Use a different memory module.
• Please contact Lenze.
Module ID (decimal) Error ID (decimal)
104: Module identification 13
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the safety module. • Use a different safety module.
• Please contact Lenze.
Module ID (decimal) Error ID (decimal)
104: Module identification 14
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The control card is not supported by the operating
system.
Consultation with Lenze required.
Module ID (decimal) Error ID (decimal)
104: Module identification 15
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The power section is not supported by the operating
system.
Consultation with Lenze required.
Module ID (decimal) Error ID (decimal)
104: Module identification 16
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The extension module in module slot MXI1 is not
supported by the operating system.
• Use a different module.
• Please contact Lenze.
