Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
897
15 Parameter reference
15.2 Parameter list | C02641
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02641
C02642
C02643
C02644
1028 DS402 homing method 28
1029 DS402 homing method 29
1030 DS402 homing method 30
1031 DS402 homing method 31
1032 DS402 homing method 32
1033 DS402 homing method 33
1034 DS402 homing method 34
1035 DS402 homing method 35
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02640 | Homing mode
Data type: UNSIGNED_32
Index: 21935
d
= 55AF
h
Parameter | Name:
C02641 | Action after detect Home position
Data type: UNSIGNED_32
Index: 21934
d
= 55AE
h
 Basic function " Homing "
Selection list (Lenze setting printed in bold)
0 Move absolute on target position
1 Move relative by Target position
2 Stop immediately
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02642 | Home position
Data type: INTEGER_32
Index: 21933
d
= 55AD
h
 Basic function " Homing "
Setting range (min. value | unit | max. value) Lenze setting
-214748.3647 Unit 214748.3647 0.0000 Unit
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02643 | Homing: Target position
Data type: INTEGER_32
Index: 21932
d
= 55AC
h
 Basic function " Homing "
Setting range (min. value | unit | max. value) Lenze setting
-214748.3647 Unit 214748.3647 0.0000 Unit
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02644 | Homing: Speed 1
Data type: INTEGER_32
Index: 21931
d
= 55AB
h
 Basic function " Homing "
Setting range (min. value | unit | max. value) Lenze setting
0.0000 Unit/s 214748.3647 360.0000 Unit/s
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
