14 Diagnostics & fault analysis
14.7 Error messages of the operating system
656
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Memory module is missing [0x00650003]
Control card is defect [0x00680000]
Power section is defect [0x00680001]
Memory module is defect or missing [0x00680002]
Module ID (decimal) Error ID (decimal)
101: Logbook module 3
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Memory module is defective or not available. Use a different memory module.
Module ID (decimal) Error ID (decimal)
104: Module identification 0
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the control card. Mains switching
• Please contact Lenze if the error occurs again.
Module ID (decimal) Error ID (decimal)
104: Module identification 1
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the power section. Mains switching
• Please contact Lenze if the error occurs again.
Module ID (decimal) Error ID (decimal)
104: Module identification 2
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the memory
module.
Mains switching
• If the error occurs again: Switch off the controller,
remove memory module and plug in again, switch on
the controller again.
• If the error still occurs: Switch off controller and use a
different memory module.
