Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
943
15
Parameter reference
15.3
Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
VFC: VVC reset time
Linear value
23616
5C40
E
1
UNSIGNED_32
100
VFC: V/f voltage boost
Linear value
23615
5C3F
E
1
INTEGER_32
1
VFC: Load - cw/ccw-operation
Selection list
23614
5C3E
E
1
UNSIGNED_32
1 CINH
VFC: Load adjustment
Linear value
23613
5C3D
E
1
UNSIGNED_32
100
VFC: Gain - Imax controller
Linear value
23612
5C3C
E
1
UNSIGNED_32
1000
VFC: Reset time - Imax controller
Linear value
23611
5C3B
E
1
UNSIGNED_32
10
VFC: Gain - slip compensation
Linear value
23610
5C3A
E
1
INTEGER_32
100
VFC: Time const. slip comp.
Linear value
23609
5C39
E
1
UNSIGNED_32
1
VFC: Gain - oscillation damping
Linear value
23608
5C38
E
1
INTEGER_32
1
VFC: Time const. - oscill. damp.
Linear value
23607
5C37
E
1
INTEGER_32
1
VFC: Limitation - oscillation damping
Linear value
23606
5C36
E
1
INTEGER_32
10
VFC: ramp-end frequ. - oscill. damp.
Linear value
23605
5C35
E
1
INTEGER_32
1
VFC: Influence - speed controller
Linear value
23604
5C34
E
1
UNSIGNED_32
100
VFC: Gain - speed controller
Linear value
23603
5C33
E
1
UNSIGNED_32
1000
VFC: Reset time - speed contr.
Linear value
23602
5C32
E
1
UNSIGNED_32
10
DC brake: Current
Linear value
23601
5C31
E
1
INTEGER_32
100
DC brake: Current for quick stop
Linear value
23600
5C30
E
1
INTEGER_32
100
DC brake: Activat. by quick stop
Selection list
23599
5C2F
E
1
UNSIGNED_32
1
Min. inh-time aft. overvolt.
Linear value
23598
5C2E
E
1
UNSIGNED_32
1
VFC: Override point of field weakening
Linear value
23595
5C2B
E
1
INTEGER_32
1
SLVC: Field current controller gain
Linear value
23590
5C26
E
1
UNSIGNED_32
100
SLVC: Cross current controller gain
Linear value
23589
5C25
E
1
UNSIGNED_32
100
SLVC: Gain - torque controller
Linear value
23588
5C24
E
1
UNSIGNED_32
10000
SLVC: Torque controller reset time
Linear value
23587
5C23
E
1
UNSIGNED_32
100
SLVC: Time const.- Para. adj.
Linear value
23586
5C22
A
2
UNSIGNED_32
1
Flying restart: Activation
Selection list
23585
5C21
E
1
UNSIGNED_32
1
Flying restart: Current
Linear value
23584
5C20
E
1
INTEGER_32
1
Flying restart: Start frequency
Linear value
23583
5C1F
E
1
INTEGER_32
10
Flying restart: Integration time
Linear value
23582
5C1E
E
1
UNSIGNED_32
1
Flying restart: Min. deviation
Linear value
23581
5C1D
E
1
UNSIGNED_32
100
Flying restart: Delay time
Linear value
23580
5C1C
E
1
UNSIGNED_32
1
VFC: Frequency setpoint
Linear value
23577
5C19
E
1
INTEGER_32
10
Sync source
Selection list
23455
5B9F
E
1
UNSIGNED_8
1
Sync cycle time
Linear value
23454
5B9E
E
1
UNSIGNED_32
1
Sync phase position
Linear value
23453
5B9D
E
1
UNSIGNED_32
1
Sync tolerance
Linear value
23452
5B9C
E
1
UNSIGNED_32
1
Sync PLL increment
Selection list
23451
5B9B
E
1
UNSIGNED_8
1
CAN SYNC application cycle
Linear value
23445
5B95
E
1
UNSIGNED_16
1
Motor thermal sensor
Selection list
23385
5B59
E
1
UNSIGNED_32
1
Spec. characteristic: temperature
Linear value
23384
5B58
A
2
UNSIGNED_32
1
Spec. characteristic: resistance
Linear value
23383
5B57
A
2
UNSIGNED_32
1
Motor temp. feedback system
Selection list
23382
5B56
E
1
UNSIGNED_16
1 CINH
Motor operating temperature
Linear value
23381
5B55
E
1
INTEGER_32
1
Influence winding I²xt mon.
Linear value
23380
5B54
E
1
UNSIGNED_32
1
S1 torque characteristic I²xt mon.
Linear value
23379
5B53
A
8
UNSIGNED_32
1
Starting value I²xt monitoring
Linear value
23378
5B52
E
1
UNSIGNED_32
1
Async. motor: Stall protection
Linear value
23377
5B51
E
1
UNSIGNED_32
1
Enhanced power
Selection list
23376
5B50
E
1
UNSIGNED_32
1 CINH
Dual motor temperature
Linear value
23375
5B4F
A
2
INTEGER_32
1
Delay time for fan start
Selection list
23374
5B4E
E
1
UNSIGNED_32
1
Code
Name
Type
Index
Data
dec
hex
DS
DA
DT
Factor
CINH
Grayed out = display parameter (read access only)
