12 Basic drive functions
12.13 Cam data management
598
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

How to change a cam:
1. Go to C02911 and set the product number of the product to be edited.
2. Go to C02940 and set the track number of the cam track to be edited.
Tip!
The cam type is displayed in
C02941 and the number of cams of the selected cam data is
displayed in C02942 .
3. Go to C02943 and set the cam to be edited.
4. Change the desired parameters of the selected cam:
• C02944 : Cam position X0
• C02945 : Cam position X1
• C02946 : Cont Time (for position/time cams)

How to change a position mark:
1. Go to C02911 and set the product number of the product to be edited.
2. Go to C02960 and set the track number of the position track to be edited.
Tip!
In
C02962 the number of the position marks of the position data selected is shown.
3. Set the position mark to be edited in C02963 .
4. Change the desired parameters of the selected position mark:
• C02964 : x position
• C02965 : y position
