Lenze E94AxPExxxx - Manual (Page 779)

Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
779
15 Parameter reference
15.2 Parameter list | C00181
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00181
C00182
C00183
C00185
Parameter | Name:
C00181 | Red. brake chopper threshold
Data type: UNSIGNED_32
Index: 24394
d
= 5F4A
h
 Braking operation
Setting range (min. value | unit | max. value) Lenze setting
0 V 100 0 V
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00182 | Time for device search function
Data type: UNSIGNED_16
Index: 24393
d
= 5F49
h
From software version V3.0
Setting range (min. value | unit | max. value) Lenze setting
0 6000 5
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00183 | Device status
Data type: UNSIGNED_32
Index: 24392
d
= 5F48
h
Display of the device state for diagnostic purposes
Selection list
(read only)
0 Operation
1 Operation/Warning active
2 Operation/warning locked act.
3 Operation/Quick stop active
4 Operation/Application stopped
10 Initialisation active
20 System fault active
90 Device is switched on
91 Device is switched on/QSP trouble
95 Device switched-on/energy saving
mode
101 Safe torque off active
102 Fault active
104 Trouble is active
141 Drive ready to start --> C00142
151 Quick stop by trouble active
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00185 | Mains recov. detect. threshold
Data type: UNSIGNED_32
Index: 24390
d
= 5F46
h
This code must not be written to by the user!
Setting range
(min. value | unit | max. value) Lenze setting
0 % 100 90 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
