5 Drive interface
5.2 Device commands
118
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.2.23 Load Lenze INV characteristic
If determination of the so-called "inverter error characteristic" is not possible with the device
command " Calculate inv. characteristic " or leads to incorrect results, the device command
C00002 = "70: Load Lenze INV characteristic" can be used to load a characteristic which is typical of
the device in question.
• Only possible when the controller is inhibited.

Tip!
Detailed information about the determination of the inverter error characteristic can be
found in the chapter "Motor interface" in the subchapter " Optimising the switching
performance of the inverter ". ( 183)
Possible status displays for this device command
Related device commands
 Calculate inv. characteristic ( 119)
Status ( C00003 ) Meaning
4621570 Device command in process
4587520 Device command executed successfully
4587521 General error
