Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
385
10 "CAN on board" system bus
10.10 Implemented CANopen objects | I-1010
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
I-1010
Save parameters with mains failure protection.
• Corresponds to device command C00002 = "11: Save start parameters".
• This command serves to save the current parameter settings of the active application with
mains failure protection in the memory module of the controller.
Read subindex 1
[10-13] Assignment of the data telegram (read access)
Write subindex 1
In addition to the index and subindex, the telegram data must also include the "save" signature
(ASCII characters; ISO 8859) so that the parameters are stored.
• A response according to the DS301 V4.02 specification occurs while writing with a wrong
identifier.
[10-14] Assignment of the data telegram (write access)
Index:
I-1010
Name:
Store parameters
Subindex Default setting Setting range (min. value | unit | max. value) Access Data type
0: highest subindex supported 1 - (read access only) ro U32
1: Save all parameters - 0 4294967295 rw U32
Subindex Meaning
Read
Write
0 Max. supported subindex: 1 -
(a write attempt triggers the error
message 0x06010002.)
1 Reading memory functions of all
parameters.
Save parameters with mains failure
protection.
8th byte 7th byte 6. byte 5th byte
Data 4 Data 3 Data 2 Data 1
Bit 31 ... bit 2 Bit 1 Bit 0
0 0/1 0/1
Bit Meaning
Bit 0 0 No saving of parameters on command.
1 Saving of parameters on command (Lenze).
Bit 1 0 No automatic saving of parameters (Lenze).
1 Automatic saving of parameters.
8th byte 7th byte 6. byte 5th byte
Data 4 Data 3 Data 2 Data 1
"e" = 0x65 "v" = 0x76 "a" = 0x61 "s" = 0x73
