Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
615
13 Oscilloscope
13.4 Operation
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

How to change a selection:
1. Go to the Vertical channel settings list field and double-click the variable to be changed in
the Name column.
2. Select a new variable in the Select variable dialog box.
3. Click OK.
• The dialog box is closed and the selection is accepted.

How to delete a selection:
1. Go to the Vertical channel settings list field and right-click the variable to be removed to
open the context menu.
2. Select the Delete command from the context menu.
Column Name Meaning
1 - Curve colour for representation in the oscillogram
2 Ch Channel number
3 On On/off
4 Inv On/off inversion
5 Name Selection of the variable to be recorded
6 Unit Scaling
7 1/Div Vertical scaling factor
8 Offset Offset value
• The offset value depends on the scaling factor. It is indicated by a dashed
line in the colour of the curve on the left-hand edge of the oscillogram.
9 Position Position value
• The position value is independent of the scaling factor. It is indicated by a
line on the left-hand edge of the oscillogram.
