14 Diagnostics & fault analysis
14.7 Error messages of the operating system
662
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Electronic nameplate: Communication error [0x0068001b]
Memory module: Faulty file system [0x0068001c]
Electronic nameplate: Checksum error [0x0068001d]
Firmware is incompatible with control card [0x0068001e]
Combination memory module/device not possible [0x0068001f]
Module ID (decimal) Error ID (decimal)
104: Module identification 27
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Communication with the electronic nameplate is
interrupted, the data could not be read.
Check correct connection of the encoder cable.
Module ID (decimal) Error ID (decimal)
104: Module identification 28
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Memory module is plugged in incorrectly or is defective. • Plug in the memory module correctly.
• Exchange defective memory module.
Module ID (decimal) Error ID (decimal)
104: Module identification 29
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The checksum of the electronic nameplate is defective. Consultation with Lenze required.
Module ID (decimal) Error ID (decimal)
104: Module identification 30
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Firmware is not compatible with the hardware. Import the compatible firmware.
Module ID (decimal) Error ID (decimal)
104: Module identification 31
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The memory module used is not supported by the
controller according to the license model.
Plug in supported module and switch the mains.
• The 9400 PLC supports the MM340 and MM440
memory modules (licence: Motion Control PLC).
