14 Diagnostics & fault analysis
14.7 Error messages of the operating system
658
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Safety module has been removed [0x00680007]
Control card is defect [0x00680008]
Power section is defect [0x00680009]
MXI1: Module is defect or missing [0x0068000a]
MXI2: Module is defect or missing [0x0068000b]
Module ID (decimal) Error ID (decimal)
104: Module identification 7
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
You have tried to remove or change the safety module
during operation.
Switch off the controller, plug in safety module and
switch on the controller again.
• If the error occurs again, the safety module is
defective and must be replaced.
Module ID (decimal) Error ID (decimal)
104: Module identification 8
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the control card. Consultation with Lenze required.
Module ID (decimal) Error ID (decimal)
104: Module identification 9
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the power section. Consultation with Lenze required.
Module ID (decimal) Error ID (decimal)
104: Module identification 10
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the extension
module in module slot MXI1.
• Use a different extension module.
• Please contact Lenze.
Module ID (decimal) Error ID (decimal)
104: Module identification 11
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the extension
module in module slot MXI2.
• Use a different extension module.
• Please contact Lenze.
