15 Parameter reference
15.2 Parameter list | C00011
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00011
C00018
C00019
C00022
C00034
Parameter | Name:
C00011 | Motor reference speed
Data type: UNSIGNED_32
Index: 24564
d
= 5FF4
h
For parameter setting via interface: In case of bigger changes, only change the setting in one step when the
controller is inhibited!
Setting range
(min. value | unit | max. value) Lenze setting
50 rpm 50000 3000 rpm
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00018 | Switching frequency
Data type: UNSIGNED_32
Index: 24557
d
= 5FED
h
Selection list (Lenze setting printed in bold) Info
2 1 kHz fixed/drive-optimised Note:
• The maximum output frequency of the controller is
limited to 1/8 of the switching frequency selected
here!
• The switching frequencies that can be selected
depend on the device type (see Hardware Manual,
chapter "Rated data").
• In the case of an offline parameter setting or when
exchanging the memory module between different
Servo Drives 9400 PLC device types, always check the
setting of this parameter and adapt it, if required, to
prevent a parameter error after the parameter set
download or module change!
3 2 kHz fixed/drive-optimised
4 4 kHz fixed/drive-optimised
5 8 kHz fixed/drive-optimised
8 2 kHz var./drive-optimised
9 4 kHz var./drive-optimised
10 8 kHz var./drive-optimised
11 16 kHz var./drive-optimised
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00019 | Threshold - standstill recognition
Data type: UNSIGNED_32
Index: 24556
d
= 5FEC
h
Setting range (min. value | unit | max. value) Lenze setting
0 rpm 450 5 rpm
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00022 | Maximum current
Data type: UNSIGNED_32
Index: 24553
d
= 5FE9
h
Setting range (min. value | unit | max. value) Lenze setting
0.00 A 21474836.47 0.00 A
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00034 | Config. analog input 1
Data type: UNSIGNED_32
Index: 24541
d
= 5FDD
h
Selection list (Lenze setting printed in bold)
0 -10...+10 V
1 -20...-4 mA, +4...+20 mA
2 -20 ... +20 mA
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
