Lenze E94AxPExxxx - Manual (Page 819)

Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
819
15 Parameter reference
15.2 Parameter list | C00573
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00573
C00574
C00576
C00577
Parameter | Name:
C00573 | Resp. to overload brake trans.
Data type: UNSIGNED_32
Index: 24002
d
= 5DC2
h
Response to activation of brake chopper monitoring
 Braking operation
Selection list (Lenze setting printed in bold)
1 Fault
2 Trouble
5 Warning
4 Warning locked
3 Quick stop by trouble
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00574 | Resp. to brake resist. overtemp.
Data type: UNSIGNED_32
Index: 24001
d
= 5DC1
h
Response to activation of brake resistor monitoring
 Braking operation
Selection list (Lenze setting printed in bold)
1 Fault
2 Trouble
5 Warning
4 Warning locked
3 Quick stop by trouble
0 No response
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00576 | Speed monitoring tolerance
Data type: UNSIGNED_32
Index: 23999
d
= 5DBF
h
Monitoring window for speed control error in [%] of nmax
Setting range
(min. value | unit | max. value) Lenze setting
0 % 100 100 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00577 | Field weakening controller gain
Data type: UNSIGNED_32
Index: 23998
d
= 5DBE
h
At "0" the P component is deactivated, a pure I-controller is used.
Setting range
(min. value | unit | max. value) Lenze setting
0.000 Vs/V 2147483.647 0.000 Vs/V
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1000
