14 Diagnostics & fault analysis
14.7 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Controller: Clamp operation [0x007b0047]
Pole position recognition cancelled [0x007b004a]
Motor switched off [0x007b004c]
EnDat encoder: Transmission error [0x007b004e]
Module ID (decimal) Error ID (decimal)
123: Motor control 71
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Actual motor current is higher than the maximum device
current ( C00789 ).
• Increase speed setpoint ramps.
• Optimise Imax controller.
Module ID (decimal) Error ID (decimal)
123: Motor control 74
Response (Lenze setting printed in bold) Setting: C00640 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
An error occurred during the pole position identification.
The pole position identification could not be completed
successfully.
• Check whether all requirements for an identification
of the pole position are fulfilled.
• Ensure that the machine is not braked or blocked
during the pole position identification.
• Repeat the pole position identification.
Module ID (decimal) Error ID (decimal)
123: Motor control 76
Response (Lenze setting printed in bold) Setting: C00597 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
From software version V2.0
Interruption of several motor cable phases.
Check cabling between the controller and motor.
Module ID (decimal) Error ID (decimal)
123: Motor control 78
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
• Encoder signal interferences (EMC).
• Encoder cable interrupted.
• Encoder defective.
• Faulty parameter setting of the encoder.
Note: This information is always supplied together with
the "I/O error - encoder communication" error message
and is entered in the logbook even if the encoder
monitoring is deactivated ( C00580 ).
• Check encoder cable, use shorter encoder cable if
required.
• Check encoder.
• Check parameter setting ( C00420 , C00421 , C00422 ).
