10
"CAN on board" system bus
10.7
Parameter data transfer
358
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
10.7.2.2
Addressing by means of index and subindex
A parameter (a Lenze code) is addressed as per the following formula:
Index = 24575 - (Lenze code number)
Example
The
parameter (motor reference speed) is to be addressed.
Calculation:
• Index:
• Decimal: 24575 - 11 = 24564
• Hexadecimal: 0x5FFF - 0xB = 0x5FF4
• Subindex: 0x00 (subindex 0 since the parameter does not have any subcodes)
Entries:
1st byte
2nd byte 3rd byte
4th byte
5th byte
6. byte
7th byte
8th byte
Command
Index
Subindex
Data 1
Data 2
Data 3
Data 4
LOW byte
HIGH
byte
LOW word
HIGH word
LOW byte
HIGH byte
LOW byte
HIGH byte
1st byte
2nd byte 3rd byte
4th byte
5th byte
6. byte
7th byte
8th byte
Command
Index
Subindex
Data 1
Data 2
Data 3
Data 4
0xF4
0x5F
0x00
