14 Diagnostics & fault analysis
14.7 Error messages of the operating system
694
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Failure of a mains phase [0x007b003f]
Brake chopper: Ixt > C00570 [0x007b0040]
Brake resistor: I2t > C00572 [0x007b0041]
Power section is defect [0x007b0042]
Module ID (decimal) Error ID (decimal)
123: Motor control 63
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Missing mains phase.
Note: This monitoring is only available for devices
≥ 75 kW (type 8S and bigger).
Check mains connection.
Module ID (decimal) Error ID (decimal)
123: Motor control 64
Response (Lenze setting printed in bold) Setting: C00569 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Frequent and too long braking. • Check drive dimensioning.
• Check setting in C00570 .
Module ID (decimal) Error ID (decimal)
123: Motor control 65
Response (Lenze setting printed in bold) Setting: C00571 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Frequent and too long braking. • Check drive dimensioning.
• Check setting in C00572 .
• Check settings for brake resistor ( C00129 , C00130 ,
C00131 ).
Module ID (decimal) Error ID (decimal)
123: Motor control 66
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Device error Mains switching
• Please contact Lenze if the problem occurs again.
