13 Oscilloscope
13.6 Variables of the motor control (oscilloscope signals)
628
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
 Signal flow - sensorless vector control ( 228)
Common.dnActualFlux Actual flux value
Current.dnActualDirectCurrent Actual D current
Current.dnActualQuadratureCurrent Actual Q current
Current.dnDirectCurrentSet D current setpoint
Current.dnQuadratureCurrentSet Q current setpoint
Frequency.dnActualRotatingFieldFrequency Current field frequency
Frequency.dnActualSlipFrequency
Actual slip frequency
Speed.dnActualMotorSpeed Actual speed value
Torque.dnTorqueSetpoint Torque setpoint
Voltage.dnActualMotorVoltage Current motor voltage
Voltage.dnDirectVoltage D voltage
Voltage.dnQuadratureVoltage Q voltage
 Signal flow - V/f control ( 244)
 Signal flow for closed loop V/f control ( 246)
Current.Current.dnActualMotorCurrent Actual motor current
Current.dnActualQuadratureCurrent Actual Q current
Frequency.dnActualRotatingFieldFrequency Current field frequency
Frequency.dnActualSlipFrequency
Actual slip frequency
Speed.dnActualMotorSpeed Current motor speed
Speed.dnSpeedSetpoint Speed setpoint
Voltage.dnActualMotorVoltage Current motor voltage
Voltage.dnOutputDirectCurrentCtrl D voltage
Voltage.dnOutputQuadratureVoltage Q voltage
 Signal flow - encoder evaluation ( 284)
Position.dnActualLoadPos Actual position
Position.dnActualMotorPos Current motor position
Speed.dnActualEncoderSpeed Current encoder speed
Speed.dnActualMotorSpeed Current motor speed
Speed.dnActualResolverSpeed Current resolver speed
 Signal flow - position follower ( 522)
Position.dnActualLoadPos Actual position
Position.dnActualMotorPos Current motor position
Position.dnContouringError Following error
Position.dnPositionSetpoint Position setpoint
Speed.dnActualMotorSpeed Current motor speed
Speed.dnOutputPosCtrl Output signal - phase controller
Speed.dnSpeedSetpoint Speed setpoint
Torque.dnTorqueSetpoint Torque setpoint
Torque.dnTotalTorqueAdd Additive torque feedforward control value
Variable of the motor control Meaning
