5 Drive interface
5.2 Device commands
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.2.22 Resolver error identification
The C00002 = "59: Resolver error identification" device command serves to detect resolver errors
which are caused when sine and cosine tracks do not magnetise orthogonally. The identified
resolver errors serve to compensate the resolver errors.
• Only possible with servo control.

Tip!
Detailed information on the resolver error compensation can be found in the chapter
"Encoder evaluation" in the subchapter " Resolver error compensation ". ( 306)
Possible status displays for this device command
Status ( C00003 ) Meaning
3900674 Device command in process
3866624 Device command executed successfully
3866625 General error
3906358 Resolver error identification cannot be executed since the wrong control type is active (no
servo control).
3906359 Resolver error identification cannot be executed since an error or trouble is active.
3906360 Resolver error identification cannot be executed because another identification is already
active.
3906361 Resolver error identification cannot be executed because of too small speed (< 500 rpm).
