15 Parameter reference
15.3 Table of attributes
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00270 Freq. - current setpoint filter Linear value 24305 5EF1 A 2 UNSIGNED_32 10
C00271 Width - current setp. filter Linear value 24304 5EF0 A 2 UNSIGNED_32 10
C00272 Depth - current setp. filter Linear value 24303 5EEF A 2 UNSIGNED_32 1
C00273 Moment of inertia Linear value 24302 5EEE A 2 UNSIGNED_32 100
C00274 Max. acceleration change Linear value 24301 5EED E 1 UNSIGNED_32 10
C00275 Signal source - speed setpoint Selection list 24300 5EEC E 1 UNSIGNED_16 1
C00276 Signal source - torque setpoint Selection list 24299 5EEB E 1 UNSIGNED_16 1
C00280 Filter time const. DC detection Linear value 24295 5EE7 E 1 UNSIGNED_32 10
C00281 Filter for PWM adjustment Selection list 24294 5EE6 E 1 UNSIGNED_8 1
C00311 CAN TPDO1 mask byte x Bit coded 24264 5EC8 A 8 BITFIELD_8 1
C00312 CAN TPDO2 mask byte x Bit coded 24263 5EC7 A 8 BITFIELD_8 1
C00313 CAN TPDO3 mask byte x Bit coded 24262 5EC6 A 8 BITFIELD_8 1
C00314 CAN TPDO4 mask byte x Bit coded 24261 5EC5 A 8 BITFIELD_8 1
C00320 CAN TPDOx identifier Bit coded 24255 5EBF A 4 BITFIELD_32 1
C00321 CAN RPDOx identifier Bit coded 24254 5EBE A 4 BITFIELD_32 1
C00322 CAN TPDOx Tx mode Linear value 24253 5EBD A 4 UNSIGNED_8 1
C00323 CAN RPDOx Rx mode Linear value 24252 5EBC A 4 UNSIGNED_8 1
C00324 CAN TPDOx delay time Linear value 24251 5EBB A 4 UNSIGNED_16 1
C00343 CAN TPDO counter Linear value 24232 5EA8 A 4 UNSIGNED_32 1
C00344 CAN RPDO counter Linear value 24231 5EA7 A 4 UNSIGNED_32 1
C00345 CAN error Selection list 24230 5EA6 E 1 UNSIGNED_8 1
C00346 CAN heartbeat activity Bit coded 24229 5EA5 E 1 BITFIELD_32 1
C00347 CAN heartbeat status Selection list 24228 5EA4 A 32 UNSIGNED_8 1
C00348 CAN status DIP switch Selection list 24227 5EA3 E 1 UNSIGNED_8 1
C00349 CAN setting - DIP switch Linear value 24226 5EA2 A 2 UNSIGNED_8 1
C00350 CAN node address Linear value 24225 5EA1 E 1 UNSIGNED_8 1
C00351 CAN baud rate Selection list 24224 5EA0 E 1 UNSIGNED_8 1
C00352 CAN slave/master Selection list 24223 5E9F E 1 UNSIGNED_8 1
C00356 CAN TPDOx cycle time Linear value 24219 5E9B A 4 UNSIGNED_16 1
C00357 CAN RPDOx monitoring time Linear value 24218 5E9A A 4 UNSIGNED_16 1
C00359 CAN status Selection list 24216 5E98 E 1 UNSIGNED_8 1
C00360 CAN telegram and error counter Linear value 24215 5E97 A 8 UNSIGNED_16 1
C00361 CAN bus load Linear value 24214 5E96 A 6 UNSIGNED_32 1
C00367 CAN SYNC Rx identifier Linear value 24208 5E90 E 1 UNSIGNED_32 1
C00368 CAN SYNC Tx identifier Linear value 24207 5E8F E 1 UNSIGNED_32 1
C00369 CAN sync transmission cycle time Linear value 24206 5E8E A 3 UNSIGNED_16 1
C00372 CAN SDO server Rx identifier Bit coded 24203 5E8B A 10 BITFIELD_32 1
C00373 CAN SDO server Tx identifier Bit coded 24202 5E8A A 10 BITFIELD_32 1
C00374 CAN SDO client node address Linear value 24201 5E89 A 10 UNSIGNED_8 1
C00375 CAN SDO client Rx identifier Bit coded 24200 5E88 A 10 BITFIELD_32 1
C00376 CAN SDO client Tx identifier Bit coded 24199 5E87 A 10 BITFIELD_32 1
C00377 CAN SDO server node address Linear value 24198 5E86 A 10 UNSIGNED_8 1
C00378 CAN delay boot-up - operational Linear value 24197 5E85 E 1 UNSIGNED_16 1
C00381 CAN Heartbeat producer time Linear value 24194 5E82 E 1 UNSIGNED_16 1
C00382 CAN guard time Linear value 24193 5E81 E 1 UNSIGNED_16 1
C00383 CAN life time factor Linear value 24192 5E80 E 1 UNSIGNED_8 1
C00385 CAN heartbeat consumer time Bit coded 24190 5E7E A 32 BITFIELD_32 1
C00386 CAN node guarding Bit coded 24189 5E7D A 32 BITFIELD_32 1
C00387 CAN Node Guarding Activity Bit coded 24188 5E7C E 1 BITFIELD_32 1
C00388 CAN node guarding status Selection list 24187 5E7B A 32 UNSIGNED_8 1
Code Name Type Index Data
dec hex DS DA DT Factor CINH
Grayed out = display parameter (read access only)
