Lenze E94AxPExxxx - Manual (Page 879)

Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
879
15 Parameter reference
15.2 Parameter list | C02549
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02549
C02550
C02552
Parameter | Name:
C02549 | Drive interface: Signals
Data type: UNSIGNED_32
Index: 22026
d
= 560A
h
Display of the digital signals of the drive interface .
Selection list (read only)
0 FALSE
1 TRUE
Subcodes Info
C02549/1 DI_bSetCInh
C02549/2 Reserved
C02549/3 Reserved
C02549/4 DI_bSwitchOn
C02549/5 Reserved
C02549/6 DI_bReady
C02549/7 DI_bFailActive
C02549/8 DI_bImpActive
C02549/9 DI_bCinhActive
C02549/10 DI_bWarningActive
C02549/11 DI_bUVDetected
C02549/12 DI_bOVDetected
C02549/13 DI_bMainSupplyOk
C02549/14 DI_bReadyToSwitchOn
C02549/15 DI_bOperationEnabled
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02550 | Setpoint interpolation
Data type: UNSIGNED_32
Index: 22025
d
= 5609
h
 Motor interface
Selection list
0 Off
1 On
Subcodes Lenze setting Info
C02550/1 1: On Position setpoint interpolat.
C02550/2 1: On Speed setpoint interpolat.
C02550/3 1: On Torque setpoint interpolat.
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02552 | Position setpoint (mctrl)
Data type: INTEGER_32
Index: 22023
d
= 5607
h
 Motor interface
Display range
(min. value | unit | max. value)
-214748.3647 Unit 214748.3647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
