Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
885
15 Parameter reference
15.2 Parameter list | C02577
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02577
C02578
C02579
C02580
Parameter | Name:
C02577 | External actual position
Data type: INTEGER_32
Index: 21998
d
= 55EE
h
 Encoder evaluation
Display range (min. value | unit | max. value)
-214748.3647 Unit 214748.3647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02578 | Offset actual pos. value/setp.
Data type: INTEGER_32
Index: 21997
d
= 55ED
h
 Encoder evaluation
Display range (min. value | unit | max. value)
-214748.3647 Unit 214748.3647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02579 | Encoder eval.: Dig. signals
Data type: UNSIGNED_32
Index: 21996
d
= 55EC
h
Display of the digital signals of the encoder evaluation .
Selection list (read only)
0 FALSE
1 TRUE
Subcodes Info
C02579/1 FDB_bResolverError
C02579/2 FDB_bSinCosSignalError
C02579/3 FDB_bEncoderComError
C02579/4 FDB_bResetPosFollowingError
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02580 | Operating mode brake
Data type: UNSIGNED_32
Index: 21995
d
= 55EB
h
 Basic function " Brake control "
Selection list (Lenze setting printed in bold)
0 Brake control off
1 Directly with brake module
2 Autom. with brake module
11 Directly - external switching
12 Autom. - external switching
22 Autom. - DC brake
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
