15 Parameter reference
15.2 Parameter list | C02670
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02670
C02671
C02672
C02673
Parameter | Name:
C02670 | Tolerance for POS_bActPosInTarget
Data type: INTEGER_32
Index: 21905
d
= 5591
h
Tolerance window for actual value-based evaluation "Target position reached"
(Output POS_bActPosInTarget)
 Basic function " Positioning "
Setting range (min. value | unit | max. value) Lenze setting
0.0000 Unit 214748.3647 0.0000 Unit
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02671 | Tolerance for POS_bDriveInTarget
Data type: INTEGER_32
Index: 21904
d
= 5590
h
From software version V2.0
Tolerance window for actual value and setpoint-based evaluation "Drive in the target"
(Output POS_bDriveInTarget)
 Basic function " Positioning "
Setting range (min. value | unit | max. value) Lenze setting
0.0001 Unit 214748.3647 2.0000 Unit
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02672 | Hysteresis for POS_bDriveInTarget
Data type: INTEGER_32
Index: 21903
d
= 558F
h
From software version V2.0
Hysteresis window for actual value and setpoint-based evaluation "Drive in the target"
(Output POS_bDriveInTarget)
 Basic function " Positioning "
Setting range (min. value | unit | max. value) Lenze setting
0.0000 Unit 214748.3647 1.0000 Unit
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02673 | Activate DriveInTarget Modulo
Data type: UNSIGNED_32
Index: 21902
d
= 558E
h
From software version V2.0
For actual value and setpoint-based evaluation "Drive in target" (output POS_bDriveInTarget):
Definition how the modulo evaluation is to be carried out if the actual position value enters the tolerance and
hysteresis window again.
 Basic function " Positioning "
Selection list (Lenze setting printed in bold)
0 Only setpoint Cycle
1 All cycles
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
