6 Motor interface
6.5 Sensorless vector control (SLVC)
216
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6.5.2.2 Motor stator resistance
For the adjustment of the motor stator resistance, first the motor current at standstill (without load
of the motor) is compared to the motor magnetising current. Afterwards the setting of the motor
stator resistance is changed step by step until the motor current stably reaches the motor
magnetising current.

How to adjust the motor stator resistance:
1. Select setpoint speed 0 rpm or activate quick stop.
2. Enable controller.
3. Compare the motor current displayed in
C00054 with the motor magnetising current
displayed in C00092 .
4. Inhibit controller.
5. If motor current > motor magnetising current:
• Reduce the motor stator resistance stepwise in C00084 .
If motor current < motor magnetising current:
• Increase the motor stator resistance stepwise in C00084 .
6. Repeat steps 2 ... 5 until the following applies: Motor current ≈ motor magnetising current.
7. Save parameter set (
C00002 = "11: Save start parameters").
