14 Diagnostics & fault analysis
14.7 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Safety module is defect or missing [0x00680003]
MXI1: Module changed during operation [0x00680004]
MXI2: Module changed during operation [0x00680005]
Memory module has been removed [0x00680006]
Module ID (decimal) Error ID (decimal)
104: Module identification 3
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
Operating system could not identify the safety module. Mains switching
• If the error occurs again: Switch off the controller,
remove safety module and plug in again, switch on
the controller again.
• If the error still occurs: Switch off controller and use a
different safety module.
Module ID (decimal) Error ID (decimal)
104: Module identification 4
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
It was tried to plug an extension module into module slot
MXI1, which is not "Hot-plug"-able.
Plug in valid module and switch on mains.
• Through mains switching, the system accepts
modules without "hot plug" capability in the
following switch-on phase.
Module ID (decimal) Error ID (decimal)
104: Module identification 5
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
It was tried to plug an extension module into module slot
MXI2, which is not "Hot-plug"-able.
Plug in valid module and switch on mains.
• Through mains switching, the system accepts
modules without "hot plug" capability in the
following switch-on phase.
Module ID (decimal) Error ID (decimal)
104: Module identification 6
Response (Lenze setting printed in bold)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
You have tried to remove or change the memory module
during operation.
Switch off the controller, plug in memory module and
switch on the controller again.
• If the error occurs again, the memory module is
defective and must be replaced.
