Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
447
12 Basic drive functions
12.5 Manual job, encoderless
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.5.1 Parameter setting
• Parameterising dialog box in»Engineer«: Tab Application parameters  Dialog level Overview 
All basic functions  Manual jog (OL)
• Short overview of the parameters for manual jog, encoderless:
Parameter Info Lenze setting
Value Unit
C02770/1 EnableManualMode 0: Deactivate
C02770/2 JogPositive 0: Deactivate
C02770/3 JogNegative 0: Deactivate
C02770/4 ActivateDataBit1 0: Deactivate
C02770/5 ActivateDataBit2 0: Deactivate
C02771/1...4 Frequency
• Field frequency f
d
with which the current vector
rotates.
1.0 Hz
C02772/1...4 Start angle 0.0 °
C02773/1...4 Current
• R.m.s. value of the current vector which is injected
with the parameterised frequency/starting angle.
• 100 % ≡ I
max_device
( C00022 )
10.00 %
C02774/1...4 Acceleration time 1.000 s
C02775/1...4 Deceleration time 1.000 s
C02776/1...4 Max. activation time 1.000 s
C02779 Mol_SetpointCurrent - A
C02780 Mol_dnState -
C02781 ManualJogOpenLoop: Dig. signals -
Highlighted in grey = display parameter

Stop!
At the frequency f
d
= 0 Hz, the r.m.s. value increases to 141 % of the current
parameterised in C02773/x . As a result, the connected motor can be destroyed!
Remedy: Activation of a derating curve in i2xt monitoring or limitation of the
parameterised current in C02773/x to 71 % of the rated motor current.  Motor
monitoring (I 2 xt) ( 263)
