Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
873
15 Parameter reference
15.2 Parameter list | C02521
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02521
C02522
C02523
C02524
C02525
Parameter | Name:
C02521 | Gearbox factor denom.: Motor
Data type: INTEGER_32
Index: 22054
d
= 5626
h
 Drive interface
Setting range (min. value | unit | max. value) Lenze setting
1 2147483647 1
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02522 | Gearbox factor num.: Pos. enc.
Data type: INTEGER_32
Index: 22053
d
= 5625
h
 Drive interface
Setting range (min. value | unit | max. value) Lenze setting
1 2147483647 1
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02523 | Gearbox fac. denom.: Pos. enc.
Data type: INTEGER_32
Index: 22052
d
= 5624
h
 Drive interface
Setting range (min. value | unit | max. value) Lenze setting
1 2147483647 1
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02524 | Feed constant
Data type: UNSIGNED_32
Index: 22051
d
= 5623
h
 Drive interface
Setting range (min. value | unit | max. value) Lenze setting
0.0001 Unit/rev. 214748.3647 360.0000 Unit/rev.
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10000
Parameter | Name:
C02525 | Unit
Data type: UNSIGNED_32
Index: 22050
d
= 5622
h
 Drive interface
Selection list (Lenze setting printed in bold) Info
0 User-defined The text entered in C02526 is displayed for the unit.
1 Incr.
2 μm
3 mm
4 m
5 inch
6 yard
7 °
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
