Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
925
15 Parameter reference
15.2 Parameter list | C02857
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02857
C02858
C02859
C02860
C02861
C02862
Parameter | Name:
C02857 | Service code
Data type: VISIBLE_STRING
Index: 21718
d
= 54D6
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C02858 | Electronic nameplate status
Data type: UNSIGNED_8
Index: 21717
d
= 54D5
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C02859 | Activate Lss sat. char.
Data type: UNSIGNED_8
Index: 21716
d
= 54D4
h
 Correction of the leakage inductance via saturation characteristic
Selection list (Lenze setting printed in bold)
0 Off
1 On
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02860 | Rr adjustment
Data type: UNSIGNED_32
Index: 21715
d
= 54D3
h
Setting range (min. value | unit | max. value) Lenze setting
50.00 % 200.00 100.00 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C02861 | Lh adjustment
Data type: UNSIGNED_32
Index: 21714
d
= 54D2
h
Setting range (min. value | unit | max. value) Lenze setting
50.00 % 200.00 100.00 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C02862 | Resolver: Gain
Data type: UNSIGNED_16
Index: 21713
d
= 54D1
h
From software version V2.0
 Resolver error compensation
Setting range (min. value | unit | max. value)
0 100
Subcodes Lenze setting Info
C02862/1 100 Gain of cosine track
C02862/2 100 Gain of sine track
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
