9 I/O terminals
9.2 Analog inputs
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.2.2 Parameter setting
Short overview of parameters for the analog inputs:
9.2.3 Reconfiguring analog input 1 into current input
By means of the following two steps, analog input 1 can be reconfigured into a current input:
1. Bridge the terminals A1R and A1- at terminal strip X3 by means of wiring.
2. Select the corresponding current loop under
C00034 .

Tip!
Like this you can implement a 4 ...20 mA current loop, e.g. for speed setpoint selection.
Open-circuit monitoring
Under
C00598 you can set an error response to open circuit for the 4 ...20 mA current loop.
Parameter Info
C00034 Config. analog input 1
C00598 Resp. to open circuit AIN1
C02730/1 Analog input 1: Gain
C02730/2 Analog input 2: Gain
C02731/1 Analog input 1: Offset
C02731/2 Analog input 2: Offset
C02732/1 Analog input 1: Dead band
C02732/2 Analog input 2: Dead band
C02800/1 Analog input 1: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)
C02800/2 Analog input 2: Input signal (-16384 ≡ -100 %, 16383 ≡ 100 %)
Highlighted in grey = display parameter
