15 Parameter reference
15.2 Parameter list | C00309
788
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00309
C00310
C00311
Parameter | Name:
C00309 | Service code
Data type: UNSIGNED_32
Index: 24266
d
= 5ECA
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00310 | Service code
Data type: UNSIGNED_8
Index: 24265
d
= 5EC9
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00311 | CAN TPDO1 mask byte x
Data type: BITFIELD_8
Index: 24264
d
= 5EC8
h
A mask can be parameterised for each byte of the TPDO1 in the assigned subcode.
• In case of an event-controlled PDO transmission, only the masked bits will be considered for event control.
• Mask "0x0" means that no bit of the corresponding byte actuates the transmission.
• Mask "0xff" means that every bit of the corresponding byte can actuate the transmission.
 "CAN on board" system bus
Setting range
0x00
0xFF
Value is bit-coded:
Bit 0 Mask bit 0
... ...
Bit 7 Mask bit 7
Subcodes Lenze setting Info
C00311/1 0x00 Mask for byte 1 ... byte 8 of TPDO1
C00311/...
C00311/8
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
