Lenze E94AxPExxxx - Manual (Page 769)

Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
769
15 Parameter reference
15.2 Parameter list | C00121
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00121
C00122
C00123
C00126
C00127
Parameter | Name:
C00121 | Warning threshold motor temperature
Data type: UNSIGNED_32
Index: 24454
d
= 5F86
h
Temperature threshold for motor temperature advance warning
• The response to reaching the threshold can be selected in C00584 .
 Motor temperature monitoring
Setting range (min. value | unit | max. value) Lenze setting
0 °C 150 120 °C
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00122 | Heatsink temp. warn. threshold
Data type: UNSIGNED_32
Index: 24453
d
= 5F85
h
Temperature threshold for heatsink temperature advance warning
• The response to reaching the threshold can be selected in C00582 .
Setting range (min. value | unit | max. value) Lenze setting
0 °C 85 85 °C
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00123 | Warning threshold device util.
Data type: UNSIGNED_32
Index: 24452
d
= 5F84
h
Adjustable threshold for I x t advance warning
• The advance warning is sent if the device utilisation ( C00064 ) is higher than the set threshold.
• The response for reaching the threshold can be selected in C00604 .
Setting range (min. value | unit | max. value) Lenze setting
0 % 100 90 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00126 | CPU temp. warning threshold
Data type: UNSIGNED_32
Index: 24449
d
= 5F81
h
Temperature threshold for advance warning of CPU temperature on the control card
• The response to reaching the threshold can be selected in C00589 .
Setting range (min. value | unit | max. value) Lenze setting
0 °C 85 70 °C
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00127 | Mot. overload warning threshold
Data type: UNSIGNED_32
Index: 24448
d
= 5F80
h
Adjustable threshold for I 2 x t advance warning
• The advance warning is sent if the thermal motor load ( C00066 ) is higher than the set threshold.
• The response for reaching the threshold can be selected in C00606 .
 I2xt motor monitoring
Setting range (min. value | unit | max. value) Lenze setting
0 % 200 100 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
