14 Diagnostics & fault analysis
14.7 Error messages of the operating system
734
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Jerk has been limited [0x00b8000e]
Position target outside the software limit positions [0x00b8000f]
Maximum speed exceeded [0x00b80010]
Maximum acceleration exceeded [0x00b80011]
Module ID (decimal) Error ID (decimal)
184: Basic drive functions 14
Response (Lenze setting printed in bold) Setting: C02716/3 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The requested S-ramp time is lower than the minimum
S-ramp time set in C02706 and has been limited to this S-
ramp time.
• Increase S-ramp time of the traversing profile of the
basic function (manual jog, homing, or positioning).
• Reduce minimum S-ramp time ( C02706 ).
• Deactivate monitoring of the limit values by the basic
function "Limiter".
Module ID (decimal) Error ID (decimal)
184: Basic drive functions 15
Response (Lenze setting printed in bold) Setting: C02716/2 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
It was tried to position to a target outside the software
limit positions.
• Select a target within the software limit positions.
• Increase permissible traversing range (change setting
of the software limit positions).
• Deactivate monitoring of the software limit positions
by the basic function "Limiter".
Module ID (decimal) Error ID (decimal)
184: Basic drive functions 16
Response (Lenze setting printed in bold) Setting: C02716/3 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The max. speed parameterised in C02703 or C00011 has
been exceeded.
• Reduce speed.
• Increase maximum speed ( C02703 ).
• Deactivate monitoring of the limit values by the basic
function "Limiter".
Module ID (decimal) Error ID (decimal)
184: Basic drive functions 17
Response (Lenze setting printed in bold) Setting: C02716/3 ( Adjustable response)
 None  System fault  Fault  Trouble  Quick stop by trouble  Warning locked  Warning  Information
Cause Remedy
The max. acceleration parameterised in C02705 has
been exceeded.
• Reduce acceleration.
• Increase maximum acceleration ( C02705 ).
• Deactivate monitoring of the limit values by the basic
function "Limiter".
