Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
609
12
Basic drive functions
12.14
Pole position identification
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.14.5
Impacts of parameter changes on the signal PPI_bPolePositionAvailable
Changing the type of motor control (C00006)
Changing relevant motor data
Changing relevant encoder data
Initial situation 1
Parameter change
Impact
• PPI_bPolePositionAvailable = TRUE
• Motor control (
) = "1: SC:
Servo control sync. motor"
another motor control is
set.
PPI_bPolePositionAvailable remains
on TRUE since the signal is irrelevant
for an asynchronous motor.
Initial situation 2
Parameter change
Impact
• PPI_bPolePositionAvailable = TRUE
• Motor control (
) =
• "2: SC: Servo control async.
motor" or
• "4: SLVC: Sensorless vector
control" or
• "6: VFCplus: V/f control" or
• "7: VFCplus: V/f control"
, the motor control "1: SC:
Servo control sync. motor" is set.
PPI_bPolePositionAvailable is reset to
FALSE since the signal is relevant for a
synchronous motor and apparently a
new motor has been selected.
Initial situation
Parameter change
Impact
PPI_bPolePositionAvailable = TRUE
One of the following parameters is
changed:
• Rated motor speed (
)
• Rated motor frequency (
• Rated motor voltage (
)
PPI_bPolePositionAvailable is reset to
FALSE since it is assumed that the
connected motor has been changed.
Initial situation
Parameter change
Impact
PPI_bPolePositionAvailable = TRUE
One of the following parameters is
changed:
• Resolver - number of pole pairs
• Encoder - number of increments
• Encoder type (
• TTL encoder signal evaluation
• Motor encoder selection (
)
PPI_bPolePositionAvailable is reset to
FALSE.
