Lenze E94AxPExxxx - Manual (Page 926)

15 Parameter reference
15.2 Parameter list | C02863
926
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02863
C02864
C02865
C02866
C02867
C02868
C02869
Parameter | Name:
C02863 | Resolver: phase correction
Data type: INTEGER_16
Index: 21712
d
= 54D0
h
From software version V2.0
 Resolver error compensation
Setting range (min. value | unit | max. value) Lenze setting
-100 100 0
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02864 | Service code
Data type: INTEGER_32
Index: 21711
d
= 54CF
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C02865 | Adaptation of Ur
Data type: UNSIGNED_32
Index: 21710
d
= 54CE
h
From software version V2.0
Setting range (min. value | unit | max. value) Lenze setting
50.00 % 200.00 100.00 %
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C02866 | Curr. control par. of C75 C76
Data type: UNSIGNED_8
Index: 21709
d
= 54CD
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C02867 | Motor phase failure volt. threshold
Data type: INTEGER_32
Index: 21708
d
= 54CC
h
Setting range (min. value | unit | max. value) Lenze setting
0.0 V 1000.0 10.0 V
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10
Parameter | Name:
C02868 | Service code
Data type: UNSIGNED_32
Index: 21707
d
= 54CB
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C02869 | Service code
Data type: UNSIGNED_32
Index: 21706
d
= 54CA
h
This code is for device-internal use only and must not be written to by the user!
