Lenze E94AxPExxxx - Manual (Page 851)

Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
851
15 Parameter reference
15.2 Parameter list | C00974
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00974
C00975
C00976
C00977
C00980
Parameter | Name:
C00974 | DC brake: Current
Data type: INTEGER_32
Index: 23601
d
= 5C31
h
 DC-injection braking
Setting range (min. value | unit | max. value) Lenze setting
0.00 A 500.00 0.00 A
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00975 | DC brake: Current for quick stop
Data type: INTEGER_32
Index: 23600
d
= 5C30
h
 DC-injection braking
Setting range (min. value | unit | max. value) Lenze setting
0.00 A 500.00 0.00 A
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00976 | DC brake: Activat. by quick stop
Data type: UNSIGNED_32
Index: 23599
d
= 5C2F
h
 DC-injection braking
Selection list (Lenze setting printed in bold)
0 Off
1 On
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00977 | Min. inh-time aft. overvolt
Data type: UNSIGNED_32
Index: 23598
d
= 5C2E
h
 V/f control
Setting range (min. value | unit | max. value) Lenze setting
1 ms 10000 500 ms
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00980 | VFC: Override point of field weakening
Data type: INTEGER_32
Index: 23595
d
= 5C2B
h
From software version V2.0
Offset of the override point for field weakening
• In the VFCplus operating mode the pull-out protection function or the maximally permissible current in the field
weakening range can be adapted.
Setting range (min. value | unit | max. value) Lenze setting
-500 Hz 500 0 Hz
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
