14
Diagnostics & fault analysis
14.7
Error messages of the operating system
652
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7864323
Motor load I²xt > C00120
Fault
-
7864322
Motor load I²xt > C00127
Warning
8060984
Motor parameter identification cancelled
Fault
-
8060965
Motor temperature: Module selected in C01193 is not available
Fault
-
8060958
Motor: actual current > C00620
Fault
8060960
Motor: actual speed > C00596
Fault
8060939
Motor: Calculated e.m.f. factor unrealistic
Information
-
8060941
Motor: Calculated flux factor unrealistic
Information
-
8060953
Motor: Calculated leakage inductance unrealistic
Information
-
8060929
Motor: Calculated motor impedance unrealistic
Information
-
8060930
Motor: Calculated mutual inductance unrealistic
Information
-
8060938
Motor: Calculated mutual inductance unrealistic
Information
-
8060937
Motor: Calculated rotor resistance unrealistic
Information
-
8060940
Motor: Calculated rotor time constant unrealistic
Information
-
8060934
Motor: Device current too low for rated magnetisation
Information
-
7798787
Motor: Overtemperature
Fault
8060932
Motor: Phase resistance too high
Information
-
7798799
Motor: PTC has triggered
No response
8060935
Motor: rated current < rated magnetisation current
Information
-
7798786
Motor: temperature > C00121
Warning
7798796
Motor: thermal detector is defective
Fault
9175063
MXI1: CAN module is missing or incompatible
Fault
9175059
MXI1: Digital frequency module is missing or incompatible
Fault
9175057
MXI1: Ethernet module is missing or incompatible
Fault
9175061
MXI1: ICM module is missing or incompatible
Fault
6815748
MXI1: Module changed during operation
Warning locked
-
6815765
MXI1: Module has been changed
Information or warning locked if
the hardware type has also
changed.
-
6815754
MXI1: Module is defective or missing
Fault
-
9175053
MXI1: Module is missing or incompatible
Fault
-
9175055
MXI1: PROFIBUS module is missing or incompatible
Fault
6815760
MXI1: Wrong module
System fault
-
9175064
MXI2: CAN module is missing or incompatible
Fault
9175060
MXI2: Digital frequency module is missing or incompatible
Fault
9175058
MXI2: Ethernet module is missing or incompatible
Fault
9175062
MXI2: ICM module is missing or incompatible
Fault
6815749
MXI2: Module changed during operation
Warning locked
-
6815766
MXI2: Module has been changed
Information or warning locked if
the hardware type has also
changed.
-
6815755
MXI2: Module is defective or missing
System fault
-
9175054
MXI2: Module is missing or incompatible
Fault
-
9175056
MXI2: PROFIBUS module is missing or incompatible
Fault
6815761
MXI2: Wrong module
System fault
-
12058634
Negative direction of rotation limited
Information
12058626
Negative limit switch has triggered
Quick stop by trouble
-
12058632
Negative software limit switch overtravelled
Quick stop by trouble
6946819
New applications loaded
Information
-
9502722
No heartbeat signal detected
System fault
-
9437194
No parameters for module in MXI1
Fault
9437195
No parameters for module in MXI2
Fault
8060944
Overcurrent detected
Fault
-
hex
dec
Error message
Response (Lenze setting)
can be set in
