15 Parameter reference
15.2 Parameter list | C00272
786
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00272
C00273
C00274
C00275
Parameter | Name:
C00272 | Depth - current setp. filter
Data type: UNSIGNED_32
Index: 24303
d
= 5EEF
h
The setting "0 dB" deactivates the current setpoint filter.
 Set current setpoint filter (band-stop filter)
Setting range (min. value | unit | max. value)
0 db 100
Subcodes Lenze setting Info
C00272/1 0 db Depth current setp. filter 1
C00272/2 0 db Depth current setp. filter 2
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00273 | Moment of inertia
Data type: UNSIGNED_32
Index: 24302
d
= 5EEE
h
Note:
The load moment of inertia must be set with regard to the motor end (i.e. considering the gearbox factors).
Setting range
(min. value | unit | max. value)
0.00 kg cm² 20000000.00
Subcodes Lenze setting Info
C00273/1 0.14 kg cm² Motor moment of inertia
C00273/2 0.00 kg cm² Load moment of inertia
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00274 | Max. acceleration change
Data type: UNSIGNED_32
Index: 24301
d
= 5EED
h
Setting range (min. value | unit | max. value) Lenze setting
0.0 %/ms 400.0 400.0 %/ms
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10
Parameter | Name:
C00275 | Signal source - speed setpoint
Data type: UNSIGNED_16
Index: 24300
d
= 5EEC
h
Selection list (Lenze setting printed in bold)
0 SpeedAdd signal
1 Differentiated PosSet signal
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
