15 Parameter reference
15.2 Parameter list | C00167
776
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00167
C00168
C00169
C00171
Parameter | Name:
C00167 | Service code
Data type: VISIBLE_STRING
Index: 24408
d
= 5F58
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00168 | Error number
Data type: UNSIGNED_32
Index: 24407
d
= 5F57
h
Display of the error number of the first error with highest priority
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00169 | Logbook - event filter
Data type: BITFIELD_32
Index: 24406
d
= 5F56
h
Bit coded word for filtering system events (trouble, warning, information)
• A set filter bit inhibits entry of the corresponding event into the logbook.
• The option that identical consecutive entries ("multiple entries") into the logbook are suppressed can be
additionally activated via bit 0. Then only the time stamp of the last (latest) entry and the number of times the
same event has occurred successively are saved.
 Logbook
Setting range Lenze setting
0x00000000 0xFFFFFFFF 0x00000001 (decimal: 1)
Value is bit-coded: ( = bit set) Info
Bit 0  No multiple entries Bits not listed are reserved for future extensions!
Bit 1  Fault
Bit 2  Trouble
Bit 3  Quick stop by trouble
Bit 4  Warning locked
Bit 5  Warning
Bit 6  Information
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00171 | Service code
Data type: UNSIGNED_32
Index: 24404
d
= 5F54
h
This code is for device-internal use only and must not be written to by the user!
