15 Parameter reference
15.2 Parameter list | C00650
834
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00650
C00651
C00691
C00692
C00693
C00694
Parameter | Name:
C00650 | PolePosId min.mov. max.perm.mov.
Data type: INTEGER_32
Index: 23925
d
= 5D75
h
Max. movement permitted during the pole position identification
 Adjustment of the pole position identification
Setting range (min. value | unit | max. value) Lenze setting
1 ° 90 20 °
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C00651 | PLI min. motion absolute cur. amp.
Data type: UNSIGNED_32
Index: 23924
d
= 5D74
h
From software version V2.0
 Adjustment of the pole position identification
Display range (min. value | unit | max. value)
0.00 A 1000.00
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00691 | Total speed setpoint
Data type: INTEGER_32
Index: 23884
d
= 5D4C
h
Display range
(min. value | unit | max. value)
-200.00 % 200.00
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00692 | Speed setpoint [%]
Data type: INTEGER_32
Index: 23883
d
= 5D4B
h
Display range (min. value | unit | max. value)
-200.00 % 200.00
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00693 | Actual speed [%]
Data type: INTEGER_32
Index: 23882
d
= 5D4A
h
Display range (min. value | unit | max. value)
-200.00 % 200.00
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
Parameter | Name:
C00694 | Speed controller output
Data type: INTEGER_32
Index: 23881
d
= 5D49
h
Display range (min. value | unit | max. value)
-200.00 % 200.00
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
