12 Basic drive functions
12.12 Brake control
554
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.12.2 Parameter setting
• Parameterisation dialog in »Engineer«: Tab Application parameters  Dialog level Overview 
All basic functions  Brake control
• Short overview of parameters for brake control:

Danger!
A faultless brake control function requires a correct setting of the different deceleration
times in the following parameters!
If the delay times are set incorrectly, a faulty control of the motor holding brake may be
caused!
In the case of the basic functions
Manual job, encoderless ( 446) and Pole position
identification ( 602) , the number of available operating modes of the holding brake is
limited. Please refer to the danger notes in the chapters indicated.
Parameter Info
C02580 Operating mode brake
C02581 Threshold - brake activation
C02582 Brake resp. to pulse inhibit
C02583 Status input monitoring
C02585 Brake control polarity
C02586 Starting torque 1
C02587 Starting torque 2
C02588 Source of starting torque
C02589 Brake closing time
C02590 Brake opening time
C02591 Waiting time - status monitoring
C02593 Waiting time - brake activation
C02594 Test torque
C02595 Permissible angle of rotation
C02596 Grinding speed
C02597 Accel./decel. time - grinding
C02598 Grinding ON time
C02599 Grinding OFF time
C02600 Acceleration time feedf. control
C02601 Reference for acceleration time of brake
C02602 Source for feedf. control brake
C02603 Threshold 1 for opening brake
C02604 Threshold 2 for opening brake
