Fan control status
Bit coded
23988
5DB4
E
1
BITFIELD_8
1
Resp. to failure t. sensor drive
Selection list
23987
5DB3
E
1
UNSIGNED_32
1
Resp. to CPU temperature > C00126
Selection list
23986
5DB2
E
1
UNSIGNED_32
1
Resp. to CAN RPDOx error
Selection list
23984
5DB0
A
4
UNSIGNED_8
1
Response to temp. sensor motor X7/X8
Selection list
23981
5DAD
E
1
UNSIGNED_32
1
Resp. to CAN bus OFF
Selection list
23980
5DAC
E
1
UNSIGNED_8
1
Threshold max. speed reached
Linear value
23979
5DAB
E
1
UNSIGNED_32
1
Resp. to motor phase failure
Selection list
23978
5DAA
E
1
UNSIGNED_32
1
Resp. to open circuit AIN1
Selection list
23977
5DA9
E
1
UNSIGNED_32
1
Motor phase failure threshold
Linear value
23976
5DA8
E
1
INTEGER_32
10
Resp. to DC bus overvoltage
Selection list
23975
5DA7
E
1
UNSIGNED_32
1
Resp. to encoder comm. error
Selection list
23974
5DA6
E
1
UNSIGNED_32
1
Resp. to device monit. > C00123
Selection list
23971
5DA3
E
1
UNSIGNED_32
1
Resp. to motor overload > C00127
Selection list
23969
5DA1
E
1
UNSIGNED_32
1
Resp. to max. speed reached
Selection list
23968
5DA0
E
1
UNSIGNED_32
1
Resp. to failure heatsink fan
Selection list
23965
5D9D
E
1
UNSIGNED_32
1
Resp. to failure integral fan
Selection list
23964
5D9C
E
1
UNSIGNED_32
1
Resp. to CAN node guarding error
Selection list
23963
5D9B
A
32
UNSIGNED_8
1
Resp. to CAN Heartbeat error
Selection list
23962
5D9A
A
32
UNSIGNED_8
1
Resp. to CAN life guarding error
Selection list
23961
5D99
E
1
UNSIGNED_8
1
Resp. to imp. device config.
Selection list
23960
5D98
A
5
UNSIGNED_32
1
No. of CRC cycles
Linear value
23957
5D95
E
1
UNSIGNED_32
1
Resp. to motor current > C00620
Selection list
23956
5D94
E
1
UNSIGNED_32
1
Ultimate motor current I_ult
Linear value
23955
5D93
E
1
UNSIGNED_32
10
Resp. to encoder pulse deviation
Selection list
23954
5D92
E
1
UNSIGNED_32
1
CAN behaviour in case of fault
Selection list
23950
5D8E
E
1
UNSIGNED_8
1
Resp to new firmw. standard dev.
Selection list
23940
5D84
E
1
UNSIGNED_32
1
Resp. to new module in MXI1
Selection list
23939
5D83
E
1
UNSIGNED_32
1
Resp. to new module in MXI2
Selection list
23938
5D82
E
1
UNSIGNED_32
1
Resp. to PLI monitoring
Selection list
23935
5D7F
E
1
UNSIGNED_32
1
PLI 360° current amplitude
Linear value
23934
5D7E
E
1
UNSIGNED_32
1
PLI 360° ramp time
Linear value
23933
5D7D
E
1
UNSIGNED_32
1
PLI 360° traversing direction
Selection list
23932
5D7C
E
1
UNSIGNED_32
1
PolePosId 360° fault tol.
Linear value
23931
5D7B
E
1
INTEGER_32
10
PolePosId 360° absolute cur. amp.
Linear value
23930
5D7A
E
1
UNSIGNED_32
100
PolePosId min.mov. cur. amp.
Linear value
23929
5D79
E
1
UNSIGNED_32
1
PolePosId min.mov. cur.rise rate
Linear value
23928
5D78
E
1
UNSIGNED_32
1
PolePosId min.mov. gain
Linear value
23927
5D77
E
1
UNSIGNED_32
100
PLI min. mov. reset time
Linear value
23926
5D76
E
1
UNSIGNED_32
100
PolePosId min.mov. max.perm.mov.
Linear value
23925
5D75
E
1
INTEGER_32
1
PolePosId min.mov. absolute cur. amp.
Linear value
23924
5D74
E
1
UNSIGNED_32
100
Total speed setpoint
Linear value
23884
5D4C
E
1
INTEGER_32
100
Speed setpoint [%]
Linear value
23883
5D4B
E
1
INTEGER_32
100
Actual speed [%]
Linear value
23882
5D4A
E
1
INTEGER_32
100
Speed controller output
Linear value
23881
5D49
E
1
INTEGER_32
100
Total torque setpoint
Linear value
23880
5D48
E
1
INTEGER_32
100
Torque setpoint [%]
Linear value
23879
5D47
E
1
INTEGER_32
100
Filtered torque setpoint
Linear value
23878
5D46
E
1
INTEGER_32
100
Actual torque [%]
Linear value
23877
5D45
E
1
INTEGER_32
100
MCTRL_dnMotorPosAct
Linear value
23805
5CFD
A
2
UNSIGNED_32
1
Code
Name
Type
Index
Data
dec
hex
DS
DA
DT
Factor
CINH
