15 Parameter reference
15.2 Parameter list | C02564
882
Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02564
C02567
C02568
Parameter | Name:
C02564 | Service code
Data type: BITFIELD_8
Index: 22011
d
= 55FB
h
From software version V3.0
 Motor interface
Setting range Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: ( = bit set) Info
Bit 0  Option 0
Bit 1  Option 1
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02567 | Control mode
Data type: UNSIGNED_32
Index: 22008
d
= 55F8
h
 Motor interface
Selection list (read only)
0 Position control
1 Speed control
2 Torque control
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02568 | Motor interface: % signals
Data type: INTEGER_32
Index: 22007
d
= 55F7
h
Display of the scaled signals of the motor interface .
Display range (min. value | unit | max. value)
-200.00 % 200.00
Subcodes Info
C02568/1 MI_dnPosCtrlAdaptLoad_n
C02568/2 MI_dnPosCtrlAdaptMotor_n
C02568/3 MI_dnSpeedCtrlAdapt_n
C02568/4 MI_dnTorqueHighLimit_n
C02568/5 MI_dnTorqueLowLimit_n
C02568/6 MI_dnTorqueCtrlAdapt_n
C02568/7 MI_dnFluxSetpoint_n
C02568/8 MI_dnInertiaAdapt_n
C02568/9 MI_dnBoostSet_n
C02568/10 MI_dnTorqueAdd_n
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 100
