Lenze · 9400 Servo PLC· Reference manual · DMS 4.0 EN · 11/2013 · TD05/06
913
15 Parameter reference
15.2 Parameter list | C02760
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C02760
C02761
C02762
C02763
C02764
Parameter | Name:
C02760 | Activate encoder
Data type: UNSIGNED_32
Index: 21815
d
= 5537
h
From software version V2.0
 Encoder evaluation: Provision of the encoder signal of input X8
Selection list (Lenze setting printed in bold)
0 Deactivated
1 Activated
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02761 | Multiturn resolution
Data type: UNSIGNED_32
Index: 21814
d
= 5536
h
From software version V2.0
 Encoder evaluation: Provision of the encoder signal of input X8
Display range (min. value | unit | max. value)
0 Rev. 2147483647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02762 | Encoderpos
Data type: INTEGER_32
Index: 21813
d
= 5535
h
From software version V2.0
 Encoder evaluation: Provision of the encoder signal of input X8
Display range (min. value | unit | max. value)
-2147483647 Steps 2147483647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02763 | Encoderrev
Data type: INTEGER_32
Index: 21812
d
= 5534
h
From software version V2.0
 Encoder evaluation: Provision of the encoder signal of input X8
Display range (min. value | unit | max. value)
-2147483647 Steps 2147483647
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 1
Parameter | Name:
C02764 | Encoderspeed
Data type: INTEGER_32
Index: 21811
d
= 5533
h
From software version V2.0
 Encoder evaluation: Provision of the encoder signal of input X8
Display range (min. value | unit | max. value)
-214748364.7 rpm 214748364.7
 Read access  Write access  CINH  PLC STOP  No transfer Scaling factor: 10
