5.7 Program instructions

746 VA Trace Analyzer / 747 VA Stand

5-222

•

The current curves obtained with the

CYCMODE

measurement mode

can normally not be evaluated. An evaluation is possible only when
just 1 ramp is used and a peak-shaped current profile is found (the
evaluation then corresponds to the case

DCTMODE

with

SSWEEP

, i.e.

waves can not be evaluated).

Adjustable parameters:

CYCMODE

I.range
Prep.cycles
Meas.cycles

RAMP

U.start
U.end
U.step
t.step

U.ox

U.start

(ramp 1)

t.step

I

cath

U

I.range

Prep.cycles

Meas.cycles

U.step

U.end

(ramp 1)

U.end
(ramp 2)

U.start
(ramp 2)

I

an

U.red

t.HMDE

t

U

t

F (Hg)

see also

(CSWEEP, CSWEEP), RAMP, HMDE, RDE

An evaluation is
possible only for
single ramps

For every measure-

ment cycle, maximum

5 ramps are possible

Area (Hg)
