5.5.3 CURVES
746 VA Trace Analyzer / 747 VA Stand
5-109
Softkeys Meaning
Display
subst.
Display substance
Switching to the display of the first substance of the selected seg-
ment.
Select
segment
Select segment
The selection of segment and VR numbers determines what segment
curve is displayed (the simultaneous display of several segment
curves is not possible). First, the softkeys carrying the segment
names must be used to select the desired segment:
Segment# Selection of the segment Segment# .
This is followed by entry of the numbers for variation V and replication
R . For this, the system window shows the message:
VR max: ## Maximum selectable VR values
Enter VR: [00] Entry of VR
For VR the numbers for the desired variation or replication must be
entered (the entry of
* is not allowed). Without entry of VR, the default
value 00 is effective for the variation 0 with replication 0 as standard.
In determinations with background compensation
(BACKGDN instructions), the background curve
Segment-Curve-00-backgnd is shown when VR = 00 is
selected. The normal curve Segment-Curve-00 is
reached by pressing the softkey .
Select
curve
Select curve
The following curves can be selected for each segment using the
softkeys:
Original Display of the original curve (original measured values)
Valid measured values
k Recognized spikes
¡ Invalid measured values (overflow)
I
U
k
k
k
In determinations with
PSAMODE, the original
curve can not be dis-
played.
Pro-
cessed
Display of the processed curve (measured values after spike elimi-
nation and possible background compensation):
Valid measured values
k Spikes still present
(can be removed manually if need be)
¡ Invalid measured values (overflow)
(can be removed manually if need be)
