5.6 Method Specifications

746 VA Trace Analyzer / 747 VA Stand

5-124

5.6.2

SEGMENTS

SEGMENTS

This dialog page is employed for the display and entry of the

segment programs (max. 8 segments). Program instructions (see

section 5.7), the associated parameters and the freely adjustable

line time are used to determine the sequence of the segments,

which are called up with the instruction

SEGMENT

in the main

program ("OPERATION SEQUENCE").
The segments are primarily used for programming of the

measured value recording using the SWEEP instructions with one

sweep being allowed per segment. However, the segments can

also be used for the programming of macros with any other

instructions.

Method: XXXXXXXX SEGMENT

........

Instructions t/s Main parameters Auxiliary parameters

ДДДДДДДДДДДДД

ДДДДДДДДДДДДД ДДДДД

ДДДДД ДДДДДДДДДДДДДДДДДДДДДДДДД

ДДДДДДДДДДДДДДДДДДДДДДДДД

## .. ............. ..... ......................... .........................

Modify

column

Modify

line

Delete

instr.

Insert

instr.

Select

segment

Delete

segment

Plot

param.

Segment

name

Softkeys

Meaning

Modify

column

Modify parameters column-by-column

Modify

line

Modify parameters line-by-line

Delete

instr.

Delete program instruction

The line selected with the field cursor is deleted.

Insert

instr.

Insert program instruction

A blank line is inserted above the line selected with the field cursor.
