5.6 Method Specifications
746 VA Trace Analyzer / 747 VA Stand
5-170
Parameter Range; Default value / Meaning
Curves
All curve plots start with a preamble containing the following details:
METROHM Name of manufacturer
746 VA TRACE ANALYZER Instrument designation
(5.746.0101) Program number
Method Method name
Mode Measurement mode
Run Run number
Curve Type of curve
(does not appear with
Curve Cal )
User User name
Determ. Name of determination
Sample Sample identification 1 or S1
(appears only with
Curve Cal )
Segment Segment name
(does not appear with
Curve Cal )
Date Date of recording
Time Time of recording
V R Number of variation V and replication R
(does not appear with
Curve Cal )
The following curves are then put out:
Curve Orig Original curve ( original )
In contrast to the screen display on the "CURVES"
page (see section 5.5.3), the measured points are
connected by a line.
Curve Proc Processed curve ( processed )
In contrast to the screen display on the "CURVES"
page (see section 5.5.3), the measured points are
connected by a line.
Curve Smth Smoothed curve ( smoothed )
The representation corresponds to the screen
display on the "CURVES" page (see section
5.5.3).
Curve Derv Derived curve ( derived )
The representation corresponds to the screen
display on the "CURVES" page (see section
5.5.3).
Curve PSA PSA curve
The smoothed substance or segment PSA curve
is plotted. The representation corresponds to the
screen display on the "CURVES" page (see sec-
tion 5.5.3).
Curve Cal Calibration curve ( calibr. )
The representation corresponds to the screen
display on the "CURVES" page (see section 5.5.3)
and depends on the selected calibration tech-
nique (standard addition, calibration curve or in-
ternal standard) and the selected run mode
(
determination or calibration ).
