2.3 747.0010 VA Stand
746 VA Trace Analyzer / 747 VA Stand
2-9
25 25 Stopper (6.2709.080)
to close the pipetting opening
27 27 Gas wash bottle (6.2405.030)
for inert gas supply
(must be filled halfway with dist. H
2
O,
see section 3.3.3)
37 37 Electrode cable ”WE”
connection for working electrode
(MME or RDE)
38 38 Multi-Mode Electrode (MME)
(6.1246.020)
details, see section 3.4
39 39 FEP tubing (6.1805.180)
for inert gas supply to measuring vessel
(attached)
40 40 Measuring head arm
carrier plate with permanently attached
measuring head, raisable
41 41 Measuring head
measuring vessel upper half made of
PTFE; with openings for electrodes,
stirrer, gas and liquid supply lines
42 42 Dummy stopper (6.1446.040)
43 43 Reference electrode
comprising 6.0728.020 Ag/AgCl Refer-
ence system and 6.1245.010 Electrolyte
vessel (details, see section 3.6)
44 44 Nipple (6.2730.030)
for mounting the 4-way microtip 47 47 or a
dummy stopper
45 45 Drive shaft (6.1246.010)
holder for stirrer tip 62 62
46 46 PTFE tube (6.1819.000)
(attached)
47 47 4-way microtip (6.1824.000)
for delivery of solutions; with 4 lengths
of PTFE tubing with connecting nipples
for 685 Dosimat/700 Dosino
48 48 Electrode cable ”RE”
connection for reference electrode 43 43
49 49 Drive belt (6.1244.020)
connection between drive wheel 52 52 and
drive shaft 45 45
50 50 PTFE tube (4.647.1350)
for inert gas delivery to gas wash bottle
27 27 (attached)
51 51 FEP tubing (6.1805.180)
for inert gas supply to MME 38 38
52 52 Drive wheel of drive motor
53 53 FEP tubing (6.1805.040)
for inert gas delivery to gas wash bottle
27 27 (attached)
54 54 Slotted screw for controlling the
inert gas flow
Note: The factory setting of ca. 20 L/h
should not be changed without good
reason!
55 55 FEP tubing (6.1805.100)
for waste solution lead-off (attached)
56 56 FEP tubing (6.1805.090)
for inert gas lead-off (attached)
57 57 FEP tubing (6.1805.180)
for inert gas supply to tapping mecha-
nism (attached)
58 58 Electrode cable ”AE”
connection for auxiliary electrode 60 60
59 59 FEP tubing (6.1805.180)
for inert gas supply to MME 38 38
60 60 Auxiliary electrode
details, see section 3.7
61 61 Dummy stopper (6.1446.040)
62 62 Dummy stopper (6.1446.040)
63 63 Stirrer tip (6.1204.090)
